Double Drum Hoist Winch has two speeds, fast and slow, mainly used for underground coal mining face, auxiliary transportation for fully mechanized mining equipment and various types of electromechanical equipment, as well as underground mining face, bottoming yard, going downhill, The mine car scheduling and material transportation work at the ground level of the coal mine can also be used for the topping of the return column of the mining face.
Double Drum Hoist Winch is composed of a medium-sized coal multi-purpose winch: it consists of a chassis, a motor, a coupling, a brake, a reducer and a reel. The underframe is a frame welded by steel. There is a channel steel on the front and rear sides. The two ends are connected by steel plates. There are rib plates in the groove. There is a steel plate welded underneath. Two steel plates are welded under the steel plate. There are three sections of small channel steel welded to the left side, and there are steel plates on the left side of the channel steel with waist-shaped holes; the motor is fixed with bolts on the other side, and the other small channel steel plate has an oval plate and a hole. The three sections of the small channel steel are welded with ribs between the two channels of steel, and the channel surface is provided with a through hole; the decelerating chrome and the reeling device are sequentially fixed on the channel surface of the chassis, the bottom surface of the channel and the plate There are a number of circular holes, and the side plates are provided with a circular hole at both ends; the main device of the winding device is composed of a shaft support, a reel, a large ring gear, an upper cover, a lower cover and a transparent cover.
