The Underground Mining Scraper Winch is a winch unit powered by a pneumatic motor that drives the reel through a gear reduction mechanism for heavy object towing, transport or consignment. The utility model has the advantages of compact structure, convenient operation, safe and reliable work, simple maintenance, stable operation and stepless speed change. As an explosion-proof traction, transportation or consignment device, it is especially suitable for oil fields, geological drilling, mining and explosive, flammable gas and other places. Applicable to an environment with an altitude of 1000 meters or less and a temperature of -40 to 60 °C.
Underground Mining Scraper Winch Operation and Maintenance
1. First the pneumatic motor, then the transmission gear starts to run. Before starting, the brake band on the reel should be braked first, and the brake lever on the large gear should be released, so that the reel does not rotate, only the large internal gear rotates.
2. If you want to start the reel, first completely loosen the brake band on the reel and then brake the brake band on the large internal gear. At this time, the reel is rotated and wound around the wire rope to work.
3. In the underground Mining Scraper Winch work process, if the pneumatic winch is to be suspended, the brake band of the large internal gear can be released, and the brake band on the reel can be braked.
4. When starting the electric vehicle, the two brakes cannot be braked at the same time, otherwise the motor will be burnt.
5, Underground Mining Scraper Winch roll brakes and bearings and other temperatures can not exceed 70 ° C, if the temperature rises sharply, stop immediately and check.
